S3: Synchronous spindle
13.3 Configuration
Extended Functions
Function Manual, 03/2013, 6FC5397-1BP40-3BA1
729
13.3.1 Response of the synchronous-spindle coupling for NC Start
The behavior of the synchronous-spindle coupling during NC Start depends on the setting in
the following machine data:
Configured synchronous-spindle coupling
Response MD21330 $MC_COUPLE_RESET_MODE_1
Maintain coupling Bit 0 = 0
Deselect coupling Bit 0 = 1
Activate configured data Bit 5 = 1
Switch the coupling on Bit 9 = 1
Programmed synchronous-spindle coupling
Response MD20112 $MC_START_MODE_MASK
Maintain coupling Bit 10 = 0
Deselect coupling Bit 10 = 1
13.3.2 Behavior of the synchronous-spindle coupling for reset
The behavior of the synchronous operation for reset and at program end depends on the
setting in the following machine data:
Configured synchronous-spindle coupling
Response MD21330
$MC_COUPLE_RESET_
MODE_1
MD20110
$MC_RESET_MODE_MASK
Maintain coupling Bit 1 = 0 Bit 0 = 1
Deselect coupling Bit 1 = 1 Bit 0 = 1
Activate configured data Bit 6 = 1 Bit 0 = 1
Programmed synchronous-spindle coupling
MD20110 $MC_RESET_MODE_MASK
Maintain coupling Bit 0 = 1, Bit 10 = 1
Deselect coupling Bit 0 = 1, Bit 10 = 0
