S3: Synchronous spindle
13.7 Data lists
Extended Functions
750 Function Manual, 03/2013, 6FC5397-1BP40-3BA1
Program code Comment
N225 FA [S2] = 0 ; Activate configured velocity (MD)
N230 SPOS[2] = IC (-7200) ; 20 rev. with configured velocity
; in neg. direction
N350 COUPOF (S2, S1) ; On-the-fly decoupling, S = S2 = 3000
N355 SPOSA[2] = 0 ; Stop FS at zero degrees
N360 G0 X0 Y0
N365 WAITS(2) ; Wait for spindle 2
N370 M5 ; Stop FS
N375 M30
13.7 Data lists
13.7.1 Machine data
13.7.1.1 NC-specific machine data
Number Identifier: $MN_ Description
10000 AXCONF_MACHAX_NAME_TAB Machine axis name
13.7.1.2 Channelspecific machine data
Number Identifier: $MC_ Description
20070 AXCONF_MACHAX_USED Machine axis number valid in channel
21300 COUPLE_AXIS_1 Definition of synchronous spindle pair
21310 COUPLING_MODE_1 Type of coupling in synchronous spindle mode
21320 COUPLE_BLOCK_CHANGE_CTRL_1 Block change behavior in synchronous spindle
operation
21330 COUPLE_RESET_MODE_1 Coupling abort behavior
21340 COUPLE_IS_WRITE_PROT_1 Coupling parameters are write-protected
