Siemens SINUMERIK Series Function Manual

H1: Manual and handwheel travel
3.12 Data lists
Extended Functions
218 Function Manual, 03/2013, 6FC5397-1BP40-3BA1
3.12.3 Signals
3.12.3.1 Signals from NC
Signal name SINUMERIK 840D sl SINUMERIK 828D
Handwheel 1 is operated DB10.DBB68 DB2700.DBB12
Handwheel 2 is operated DB10.DBB69 DB2700.DBB13
Handwheel 3 is operated DB10.DBB70 -
Handwheel 4 is operated DB10.DBB242 -
Handwheel 5 is operated DB10.DBB243 -
Handwheel 6 is operated DB10.DBB244 -
Ethernet handwheel is stationary DB10.DBB245 -
3.12.3.2 Signals to mode group
Signal name SINUMERIK 840D sl SINUMERIK 828D
Mode Group1: JOG mode DB11.DBX0.2 DB3000.DBX0.2
Mode group2: JOG mode DB11.DBX20.2 -
Mode group3: JOG mode DB11.DBX40.2 -
Mode group4: JOG mode DB11.DBX60.2 -
Mode group5: JOG mode DB11.DBX80.2 -
Mode group6: JOG mode DB11.DBX100.2 -
Mode group7: JOG mode DB11.DBX120.2 -
Mode group8: JOG mode DB11.DBX140.2 -
Mode group9: JOG mode DB11.DBX160.2 -
Mode group10: JOG mode DB11.DBX180.2 -
3.12.3.3 Signals from mode group
Signal name SINUMERIK 840D sl SINUMERIK 828D
Mode Group1: Active mode JOG DB11.DBX6.2 DB3100.DBX0.2
Mode group2: Active mode JOG DB11.DBX26.2 -
Mode group3: Active mode JOG DB11.DBX46.2 -
Mode group4: Active mode JOG DB11.DBX66.2 -
Mode group5: Active mode JOG DB11.DBX86.2 -
Mode group6: Active mode JOG DB11.DBX106.2 -
Mode group7: Active mode JOG DB11.DBX126.2 -
Mode group8: Active mode JOG DB11.DBX146.2 -
