W4: Grinding-specific tool offset and tool monitoring
17.7 Data lists
Extended Functions
834 Function Manual, 03/2013, 6FC5397-1BP40-3BA1
17.7 Data lists
17.7.1 Machine data
17.7.1.1 General machine data
Number Identifier: $MN_ Description
18094 MM_NUM_CC_TDA_PARAM Number of TDA
18096 MM_NUM_CC_TOA_PARAM Number of TOA
18100 MM_NUM_CUTTING_EDGES_IN_TOA Tool offsets per TOA
17.7.1.2 Channelspecific machine data
Number Identifier: $MC_ Description
20254 ONLINE_CUTCOM_ENABLE Enable online tool radius compensation
20350 TOOL_GRIND_AUTO_TMON Automatic tool monitoring
20610 ADD_MOVE_ACCEL_RESERVE Acceleration reserve for overlaid movements
17.7.1.3 Axis/spindlespecific machine data
Number Identifier: $MA_ Description
32020 JOG_VELO JOG axis velocity
35032 SPIND_FUNC_RESET_MODE Parameterization of GWPS function
17.7.2 Signals
17.7.2.1 Signals from axis/spindle
Signal name SINUMERIK 840D sl SINUMERIK 828D
Geometry monitoring DB31, ... .DBX83.3 DB390x.DBX2001.3
Speed monitoring DB31, ... .DBX83.6 DB390x.DBX2001.6
GWPS active DB31, ... .DBX84.1 DB390x.DBX2002.1
