Siemens SINUMERIK Series Function Manual

Z2: NC/PLC interface signals
18.7 Measurement (M5)
Extended Functions
Function Manual, 03/2013, 6FC5397-1BP40-3BA1
887
18.7 Measurement (M5)
18.7.1 Signals from NC (DB10)
DB10
DBX107.0 and
DBX107.1
Probe actuated
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or
edge change 0 → 1
Probe 1 or 2 is actuated.
Signal state 0 or
edge change 1 → 0
Probe 1 or 2 is not actuated.
References Equipment Manual NCU
18.7.2 Signals from axis/spindle (DB31, ...)
DB31, ...
DBX62.3 Measuring status
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or
edge change 0 → 1
The "Measuring" function is active.
This signal is used during measuring and displays the current measuring status of the axis.
Signal state 0 or
edge change 1 → 0
The "Measuring" function is not active.
