Siemens SINUMERIK Series Function Manual

M5: Measurement
7.5 Setting zeros, workpiece measuring and tool measuring
Extended Functions
460 Function Manual, 03/2013, 6FC5397-1BP40-3BA1
Value Description
9 Stud Measuring a shaft
10 * Tool length Measuring the tool length
11 * ToolDiameter Measuring the tool diameter
12 Slot Measuring a groove
13 Plate Measuring a web
14 Set_Pos Preset actual value for geometric and special axes
15 Set_AuxPos Preset actual value memory for special axes only
16 Edge_2P Measuring an inclined edge
17 Plane_Angles Angle of a plane
18 Plane_Normal Angle of a plane with setpoint input
19 Dimension_1 1-dimensional setpoint value
20 Dimension_2 2-dimensional setpoint value
21 Dimension_3 3-dimensional setpoint value
22 * ToolMagnifier ShopTurn: Measurement of tool lengths with zoom-in
function
23 * ToolMarkedPos ShopTurn: Measuring a tool length with marked position
24 Coordinate transformation Coordinate transformation of a position
25 Rectangle Measurement of a rectangle
26 Save Saving data management frames
27 Restore Restoring data management frames
28 Taper turning Additive rotation of the plane
* Types of workpiece measurement
The individual methods are listed under "Types of workpiece measurement" or "Types of tool
measurement"and explained in more detail using an appropriate programming example.
7.5.2.3 Output values
Calculation results
If a setpoint position has been specified, the resulting frame is entered in result frame
$AC_MEAS_FRAME. This frame can be read and written in the part program. The result
frame is calculated according to the selected frame.
If no frame has been selected, the result frame determines the final translation and rotation
in the WCS. This frame can be entered in the selected frame using the PI service
_N_SETUDT and parameter type no. 7. Once it has been entered, the result frame is
deleted.
Table 7- 4 Output values of calculation results
Type System variable Description
FRAME $AC_MEAS_FRAME Result frame
REAL $AC_MEAS_WP_ANGLE Calculated workpiece position angle α
