Siemens SINUMERIK Series Function Manual

P2: Positioning axes
10.10 Data lists
Extended Functions
Function Manual, 03/2013, 6FC5397-1BP40-3BA1
639
10.10.3.2 Signals from channel
Signal name SINUMERIK 840D sl SINUMERIK 828D
All axes stationary DB21, ... .DBX36.3 DB3300.DBX4.3
Travel command minus DB21, ... .DBX40.6 DB3300.DBX1000.6
Travel command plus DB21, ... .DBX40.7 DB3300.DBX1000.7
10.10.3.3 Signals to axis/spindle
Signal name SINUMERIK 840D sl SINUMERIK 828D
Feedrate override, axis-specific DB31, ... .DBB0 DB380x.DBB0
Controller enable DB31, ... .DBX2.1 DB380x.DBX2.1
Delete distance-to-go spindle reset for specific axes DB31, ... .DBX2.2 DB380x.DBX2.2
Reset DB31, ... .DBX28.1 -
Continue DB31, ... .DBX28.2 -
Stop along braking ramp DB31, ... .DBX28.6 -
PLC-controlled axis DB31, ... .DBX28.7 -
10.10.3.4 Signals from axis/spindle
Signal name SINUMERIK 840D sl SINUMERIK 828D
Exact stop coarse DB31, ... .DBX60.6 DB390x.DBX0.6
Exact stop fine DB31, ... .DBX60.7 DB390x.DBX0.7
Axial alarm DB31, ... .DBX61.1 DB390x.DBX1.1
Axis ready (AX_IS_READY) DB31, ... .DBX61.2 DB390x.DBX1.2
Axis container rotation active DB31, ... .DBX62.7 -
AXRESET DONE DB31, ... .DBX63.0 -
PLC-controlled axis DB31, ... .DBX63.1 -
Axis stop active DB31, ... .DBX63.2 DB390x.DBX3.2
Travel command minus DB31, ... .DBX64.6 DB390x.DBX4.6
Travel command plus DB31, ... .DBX64.7 DB390x.DBX4.7
Positioning axis DB31, ... .DBX76.5 DB390x.DBX1002.5
F function (feedrate) for positioning axis DB31, ... .DBB78-81 -
Emergency retraction active DB31, ... .DBX98.7 DB390x.DBX5002.7
