K5: Mode groups, channels, axis interchange
5.6 Data lists
Extended Functions
Function Manual, 03/2013, 6FC5397-1BP40-3BA1
343
5.6 Data lists
5.6.1 Machine data
5.6.1.1 General machine data
Number Identifier: $MN_ Description
10010 ASSIGN_CHAN_TO_MODE_GROUP[n] Channel valid in mode group [Channel No.]: 0, 1
10722 AXCHANGE_MASK Parameterization of the axis replacement response
5.6.1.2 Channel-specific machine data
Basic machine data of channel
Number Identifier: $MC_ Description
20000 CHAN_NAME Channel name
20050 AXCONF_GEOAX_ASSIGN_TAB[n] Assignment of geometry axis to channel axis
[GEOAxisNo.]: 0...2
20060 AXCONF_GEOAX_NAME_TAB[n] Geometry axis name in channel
[GEOAxisNo.]: 0...2
20070 AXCONF_MACHAX_USED[n] Machine axis number valid in channel
[Channel axis No. ]: 0...7
20080 AXCONF_CHANAX_NAME_TAB[n] Name of channel axis in the channel
[Channel axis No.]: 0...7
20090 SPIND_DEF_MASTER_SPIND Initial setting of master spindle in channel
20100 DIAMETER_AX_DEF Geometry axis with transverse axis function
20110 RESET_MODE_MASK Determination of basic control settings after Reset/TP
End
20112 START_MODE_MASK Determination of basic control settings after NC start
20150 GCODE_RESET_VALUES[n] Reset G groups
[G-Group No.]: 0...59
20160 CUBIC_SPLINE_BLOCKS Number of blocks for C spline
20170 COMPRESS_BLOCK_PATH_LIMIT Maximum traversing length of NC block for
compression
20200 CHFRND_MAXNUM_DUMMY_BLOCKS Empty blocks with phase/radii
20210 CUTCOM_CORNER_LIMIT Max. angle for intersection calculation with tool radius
compensation
20220 CUTCOM_MAX_DISC Maximum value with DISC
