Siemens SINUMERIK Series Function Manual

K5: Mode groups, channels, axis interchange
5.6 Data lists
Extended Functions
344 Function Manual, 03/2013, 6FC5397-1BP40-3BA1
Number Identifier: $MC_ Description
20230 CUTCOM_CURVE_INSERT_LIMIT Maximum angle for intersection calculation with tool
radius compensation
20240 CUTCOM_MAXNUM_CHECK_BLOCKS Blocks for predictive contour calculation with tool
radius compensation
20250 CUTCOM_MAXNUM_DUMMY_BLOCKS Max. no. of dummy blocks with no traversing
movements with TRC
20270 CUTTING_EDGE_DEFAULT Basic setting of tool cutting edge without programming
20400 LOOKAH_USE_VELO_NEXT_BLOCK Look Ahead to programmed following block velocity
20430 LOOKAH_NUM_OVR_POINTS Number of override switch points for Look Ahead
20440 LOOKAH_OVR_POINTS[n] Override switch points for LookAhead
[Switch point No.]: 0...1
20500 CONST_VELO_MIN_TIME Minimum time with constant velocity
20600 MAX_PATH_JERK Pathrelated maximum jerk
20610 ADD_MOVE_ACCEL_RESERVE Acceleration reserve for overlaid movements
20650 THREAD_START_IS_HARD Acceleration behavior of axis with thread cutting
20700 REFP_NC_START_LOCK NC start disable without reference point
20750 ALLOW_GO_IN_G96 G0 logic in G96
20800 SPF_END_TO_VDI Subprogram end to PLC
21000 CIRCLE_ERROR_CONST Circle end point monitoring constant
21010 CIRCLE_ERROR_FACTOR Circle end point monitoring factor
21100 ORIENTATION_IS_EULER Angle definition for orientation programming
21110 X_AXIS_IN_OLD_X_Z_PLANE Coordinate system for automatic Frame definition
21200 LIFTFAST_DIST Traversing path for fast retraction from the contour
21250 START_INDEX_R_PARAM Number of first channelspecific R parameter
Auxiliary function settings of the channel
Number Identifier: $MC_ Description
22000 AUXFU_ASSIGN_GROUP[n] Auxiliary function group
[aux. func. no. in channel]: 0...49
22010 AUXFU_ASSIGN_TYPE[n] Auxiliary function type
[aux. func. no. in channel]: 0...49
22020 AUXFU_ASSIGN_EXTENSION[n] Auxiliary function extension
[aux. func. no. in channel]: 0...49
22030 AUXFU_ASSIGN_VALUE[n] Auxiliary function value
[aux. func. no. in channel]: 0...49
22200 AUXFU_M_SYNC_TYPE Output timing of M functions
22210 AUXFU_S_SYNC_TYPE Output timing of S functions
22220 AUXFU_T_SYNC_TYPE Output timing of T functions
22230 AUXFU_H_SYNC_TYPE Output timing of H functions
