Siemens SINUMERIK Series Function Manual

H1: Manual and handwheel travel
3.12 Data lists
Extended Functions
Function Manual, 03/2013, 6FC5397-1BP40-3BA1
219
Signal name SINUMERIK 840D sl SINUMERIK 828D
Mode group9: Active mode JOG DB11.DBX166.2 -
Mode group10: Active mode JOG DB11.DBX186.2 -
3.12.3.4 Signals to channel
Signal name SINUMERIK 840D sl SINUMERIK 828D
Activate DRF DB21, ... .DBX0.3 DB3200.DBX0.3
Geometry axis 1: Activate handwheel DB21, ... .DBX12.0-2 DB3200.DBX1000.0-2
Geometry axis 1: Traversing key lock DB21, ... .DBX12.4 DB3200.DBX1000.4
Geometry axis 1: Rapid traverse override DB21, ... .DBX12.5 DB3200.DBX1000.5
Geometry axis 1: Traversing keys minus/plus DB21, ... .DBX12.6-7 DB3200.DBX1000.6-7
Geometry axis 1: Machine function 1 INC ... Var. INC DB21, ... .DBX13.0-5 DB3200.DBX1001.0-5
Geometry axis 1: Invert handwheel direction of rotation DB21, ... .DBX15.0 DB3200.DBX1003.0
Geometry axis 2: Activate handwheel DB21, ... .DBX16.0-2 DB3200.DBX1004.0-2
Geometry axis 2: Traversing key lock DB21, ... .DBX16.4 DB3200.DBX1004.4
Geometry axis 2: Rapid traverse override DB21, ... .DBX16.5 DB3200.DBX1004.5
Geometry axis 2: Traversing keys minus/plus DB21, ... .DBX16.6-7 DB3200.DBX1004.6-7
Geometry axis 2: Machine function 1 INC ... Var. INC DB21, ... .DBX17.0-5 DB3200.DBX1005.0-5
Geometry axis 2: Invert handwheel direction of rotation DB21, ... .DBX19.0 DB3200.DBX1007.0
Geometry axis 3: Activate handwheel DB21, ... .DBX20.0-2 DB3200.DBX1008.0-2
Geometry axis 3: Traversing key lock DB21, ... .DBX20.4 DB3200.DBX1008.4
Geometry axis 3: Rapid traverse override DB21, ... .DBX20.5 DB3200.DBX1008.5
Geometry axis 3: Traversing keys minus/plus DB21, ... .DBX20.6-7 DB3200.DBX1008.6-7
Geometry axis 3: Machine function 1 INC ... Var. INC DB21, ... .DBX21.0-5 DB3200.DBX1009.0-5
Geometry axis 3: Invert handwheel direction of rotation DB21,... .DBX23.0 DB3200.DBX1011.0
Activate contour handwheel DB21, ... .DBX30.0-2 DB3200.DBX14.0-2
Contour handwheel simulation on DB21, ... .DBX30.3 DB3200.DBX14.3
Contour handwheel simulation negative direction DB21, ... .DBX30.4 DB3200.DBX14.4
Invert contour handwheel direction of rotation DB21, ... .DBX31.5 DB3200.DBX15.5
Orientation axis 1: Activate handwheel DB21, ... .DBX320.0-2 -
Orientation axis 1: Traversing key lock DB21, ... .DBX320.4 -
Orientation axis 1: Rapid traverse override DB21, ... .DBX320.5 -
Orientation axis 1: Traversing keys minus/plus DB21, ... .DBX320.6-7 -
Orientation axis 1:
Machine function 1 INC ... Var. INC DB21, ... .DBX321.0-5 -
Orientation axis 1: Invert handwheel direction of rotation DB21, ... .DBX323.0 -
Orientation axis 2: Activate handwheel DB21, ... .DBX324.0-2 -
Orientation axis 2: Traversing key lock DB21, ... .DBX324.4 -
Orientation axis 2: Rapid traverse override DB21, ... .DBX324.5 -
