M1: Kinematic transformation
6.11 Data lists
Extended Functions
Function Manual, 03/2013, 6FC5397-1BP40-3BA1
437
Number Identifier: $MC_ Description
24434 TRAFO_GEOAX_ASSIGN_TAB_5 Geo-axis assignment for 5th transformation
24436 TRAFO_INCLUDES_TOOL_5 Tool handling with active transformation 5.
24440 TRAFO_TYPE_6 Definition of the 6th transformation in channel
24442 TRAFO_AXES_IN_6 Axis assignment for the 6th transformation
24444 TRAFO_GEOAX_ASSIGN_TAB_6 Assignment geometry axes for 6th transformation
24446 TRAFO_INCLUDES_TOOL_6 Tool handling with active transformation 6.
24450 TRAFO_TYPE_7 Definition of the 7th transformation in channel
24452 TRAFO_AXES_IN_7 Axis assignment for the 7th transformation
24454 TRAFO_GEOAX_ASSIGN_TAB_7 Geo-axis assignment for 7th transformation
24456 TRAFO_INCLUDES_TOOL_7 Tool handling with active transformation 7.
24460 TRAFO_TYPE_8 Definition of the 8th transformation in channel
24462 TRAFO_AXES_IN_8 Axis assignment for the 8th transformation
24464 TRAFO_GEOAX_ASSIGN_TAB_8 Geo-axis assignment for 8th transformation
24466 TRAFO_INCLUDES_TOOL_8 Tool handling with active transformation 8.
24470 TRAFO_TYPE_9 Definition of the 9th transformation in channel
24472 TRAFO_AXES_IN_9 Axis assignment for the 9th transformation
24474 TRAFO_GEOAX_ASSIGN_TAB_9 Geo-axis assignment for 9th transformation
24476 TRAFO_INCLUDES_TOOL_9 Tool handling with active transformation 9.
24480 TRAFO_TYPE_10 Definition of the 10th transformation in channel
24482 TRAFO_AXES_IN_10 Axis assignment for the 10th transformation
24484 TRAFO_GEOAX_ASSIGN_TAB_10 Geo-axis assignment for 10th transformation
24486 TRAFO_INCLUDES_TOOL_10 Tool handling with active transformation 10.
24800 TRACYL_ROT_AX_OFFSET_1 Deviation of rotary axis from zero position in degrees (1st
TRACYL)
24808 TRACYL_DEFAULT_MODE_1 Selection of TRACYL mode (1st TRACYL)
24810 TRACYL_ROT_SIGN_IS_PLUS_1 Sign of rotary axis for TRACYL (1st TRACYL)
24820 TRACYL_BASE_TOOL_1 Distance of tool zero point from origin of geo-axes (1st
TRACYL)
24850 TRACYL_ROT_AX_OFFSET_2 Deviation of rotary axis from zero position in degrees (2nd
TRACYL)
24858 TRACYL_DEFAULT_MODE_2 Selection of TRACYL mode (2nd TRACYL)
24860 TRACYL_ROT_SIGN_IS_PLUS_2 Sign of rotary axis for TRACYL (2nd TRACYL)
24870 TRACYL_BASE_TOOL_2 Distance of tool zero point from origin of geo-axes (2nd
TRACYL)
22534 TRAFO_CHANGE_M_CODE M code for transformation changeover
