M5: Measurement
7.5 Setting zeros, workpiece measuring and tool measuring
Extended Functions
510 Function Manual, 03/2013, 6FC5397-1BP40-3BA1
The values of the following input variables are evaluated for measurement type 23:
Input variable Description
$AC_MEAS_VALID Validity bits for input variables
$AA_MEAS_POINT1[axis] Current or marked position
$AC_MEAS_P1_COORD Coordinate system of the measuring point *
$AA_MEAS_SETPOINT[axis] Setpoint position (minimum one geo axis must be specified)
$AC_MEAS_SET_COORD Coordinate system of setpoint *
$AC_MEAS_ACT_PLANE Calculated as active plane unless otherwise specified *
$AC_MEAS_T_NUMBER Calculated as active T unless otherwise specified (T0) *
$AC_MEAS_D_NUMBER Calculated as active D unless otherwise specified (D0) *
$AC_MEAS_TOOL_MASK Tool position, radius *
$AC_MEAS_DIR_APPROACH Approach direction *
$AC_MEAS_INPUT[0] = 1 the calculated tool lengths are written to the data management *
$AC_MEAS_TYPE 23
* optional
The following output variables are written for measurement type 23:
Output variable Description
$AC_MEAS_RESULT[0] Tool length in x
$AC_MEAS_RESULT[1] Tool length in y
$AC_MEAS_RESULT[2] Tool length in z
$AC_MEAS_RESULT[3] Tool length L1
$AC_MEAS_RESULT[4] Tool length L2
$AC_MEAS_RESULT[5] Tool length L3
