M5: Measurement
7.9 Data lists
Extended Functions
534 Function Manual, 03/2013, 6FC5397-1BP40-3BA1
Identifier Meaning
$AC_MEAS_CHSFR Frame chain setting: System frames
$AC_MEAS_NCBFR Frame chain setting: Global basic frames
$AC_MEAS_CHBFR Frame chain setting: Channel basic frames
$AC_MEAS_UIFR Frame chain setting: Settable frames
$AC_MEAS_PFRAME Frame chain setting: Program frame
$AC_MEAS_T_NUMBER Tool selection
$AC_MEAS_D_NUMBER Cutting edge selection
$AC_MEAS_TOOL_MASK Tool settings
$AC_MEAS_TYPE Measuring type
$AC_MEAS_INPUT Measurement input parameters
Table of all the output values
Identifier Meaning
$A_PROBE[1,2] Probe status
$A_PROBE_LIMITED[1,2] Measuring velocity exceeded
$AC_MEA[1,2] Probe has responded
$AA_MM Acquired probe position (MCS)
$AA_MM1...4 Probe position 1st to 4th trigger event (MCS)
$AA_MW Acquired probe position (WCS)
$AA_MW1...4 Probe position 1st to 4th trigger event (WCS)
$AC_MEAS_FRAME Result frame
$AC_MEAS_WP_ANGLE Calculated workpiece position angle
$AC_MEAS_CORNER_ANGLE Calculated angle of intersection
$AC_MEAS_DIAMETER Calculated diameter
$AC_MEAS_TOOL_LENGTH Calculated tool length
$AC_MEAS_RESULTS Measurement results (depending on measurement type)
