Siemens SINUMERIK Series Function Manual

S3: Synchronous spindle
13.1 Brief description
Extended Functions
Function Manual, 03/2013, 6FC5397-1BP40-3BA1
717
Example
Block change behavior after COUPON
Program code Comment
; IS "Disable synchronization"
; set (DB31, ... DBX31.5) = 1 for S2
N51 SPOS=10 SPOS[2]=10 ; Positions correspond to an offset
; of 0°
N52 COUPDEF(S2,S1,1,1,"FINE","DV")
N53 COUPON(S2,S1,77) ; Actual offset of 0 degrees is retained
; no following spindle movement,
; VDI signals
; IS "Synchronism coarse"
; (DB31, ... DBX98.1) and
; IS "Synchronism fine"
; (DB31, ... DBX98.0)
; are set and the block change
; enabled.
N54 M0
N57 COUPOF(S2,S1)
N99 M30
Reset and recovery
Resetting the IS "Disable synchronization" (DB31, ... DBX31.5) has no effect on the following
spindle offset. If the offset motion of the following spindle has been suppressed by the VDI
interface signal, then the offset is not automatically applied when the VDI signal is reset.
Synchronization is recovered as follows:
● By repeating the part program operation
COUPON (FS, LS, offset) with IS "Disable
synchronization" (DB31, ... DBX31.5) = 0.
COUPON (FS, LS, offset) can be written e.g. in an ASUB.
● By setting the IS "Resynchronize" (DB31, ... DBX31.4) = 1
