Page #860 background imageLoading...
Page #860 background image
Z2: NC/PLC interface signals
18.3 Manual and Handwheel Travel (H1)
Extended Functions
860 Function Manual, 03/2013, 6FC5397-1BP40-3BA1
DB10
DBX100.6, 101.6,
102.6
Handwheel selected (for handwheel 1, 2 or 3)
Edge evaluation: no Signal(s) updated: Cyclic
Signal state 1 or
edge change 0 → 1
The operator has selected the handwheel for the defined axis via the operator panel front (i.e.
activated). This information is made available by the basic PLC program at the HMI interface.
The basic PLC program sets the interface signal:
DB21, ... DBX12.0-12.2 ff (Activate handwheel)
for the defined axis to "1".
The associated axis is also displayed at the HMI interface:
DB10 DBX100.7 ff (machine axis)
and
DB10 DBB100 ff (axis number for handwheel 1).
As soon as the handwheel is active, the axis can be traversed in JOG mode with the handwheel
(DB21, ... DBX40.0-40.2 ff (Handwheel active).
Signal state 0 or
edge change 1 → 0
The operator has disabled the handwheel for the defined axis via the operator panel front. This
information is made available by the basic PLC program at the HMI interface.
The basic PLC program can set the interface signal:
DB21, ... DBX12.0-12.2 ff (Activate handwheel)
for the defined axis to "0".
Corresponding to .... DB10 DBB100 ff (axis number)
DB10 DBX100.7 ff (machine axis)
DB21, ... DBX12.0-12.2 ff (activate handwheel)
DB21, ... DBX40.0 - DBX40.2 ff (handwheel active)
DB31, ... DBX4.0 - DBX4.2 (activate handwheel)
DB10 DBB97 ff (channel number geometry axis for handwheel 1, 2 or 3)
DB10
DBX100.7, 101.7,
102.7
Machine axis (for handwheel 1, 2 or 3)
Edge evaluation: no Signal(s) updated: Cyclic
Signal state 1 or
edge change 0 → 1
The operator has assigned an axis to the handwheel (1, 2, 3) directly on the operator panel front.
This axis is a machine axis.
For further information see IS "Axis number".
Signal state 0 or
edge change 1 → 0
The operator has assigned an axis to the handwheel (1, 2, 3) directly on the operator panel front.
This axis is a geometry axis.
For further information see IS "Axis number".
Corresponding
to ....
DB10 DBB100 ff (axis number)
DB10 DBX100.6 ff (handwheel selected)
DB10 DBB97 ff (channel number geometry axis for handwheel 1, 2 or 3)
