Z2: NC/PLC interface signals
18.3 Manual and Handwheel Travel (H1)
Extended Functions
878 Function Manual, 03/2013, 6FC5397-1BP40-3BA1
DB31, ...
DBB4
Bit 7, 6
Plus and minus traverse keys
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 The selected machine axis can be traversed in both directions in JOG mode using the traversing
keys "plus" and "minus".
Depending on the active machine function, as well as the settings:
• JOG (continuous)
SD41050 $SN_JOG_CONT_MODE_LEVELTRIGGRD (jog/ continuous operation for JOG
continuous)
• JOG-INC (INC and REF in the jog mode)
MD11300 $MN_JOG_INC_MODE_LEVELTRIGGRD
for a signal change, different responses are initiated.
Case 1: Continuous traversal in jog mode
The machine axis traverses in the direction concerned as long as the interface signal
is set to 1 (and as long as the axis position has not reached an activated limitation).
Case 2:Continuous traversal in continuous mode
On the first edge change 0 →1 the machine axis starts to traverse in the relevant direction. This
traversing movement still continues when the edge changes from 1 → 0. Any new edge change
0 →1 (same traversing direction!) stops the traversing movement.
Case 3:Incremental traversal in jog mode
With signal 1 the machine axis starts to traverse at the set increment. If the signal changes to the 0
state before the increment is traversed, the traversing movement is interrupted. When the signal
state changes to 1 again, the movement is continued. The axis can be stopped and started several
times as described above until it has traversed the complete increment.
Case 4: Incremental traversal in continuous mode
On the first edge change 0 → 1 the machine axis starts to traverse at the set increment. If another
edge change 0 → 1 is performed with the same traverse signal before the axis has traversed the
increment, the traversing movement will be cancelled. The increment traversing will then not be
completed.
If both traverse signals (plus and minus) are set at the same time there is no movement or a
current movement is aborted.
The effect of the traverse keys can be disabled for every machine axis individually with the PLC
interface signal:
DB31, ... DBX4.4 (Traverse key disable)
.
Signal state 0 See cases 1 to 4 above.
Signal irrelevant for
...
Operating modes AUTOMATIC and MDA
Application
example(s)
The machine axis cannot be traversed in JOG mode if it is already being traversed via the channel-
specific PLC interface (as a geometry axis).
Alarm 20062 is signaled.
Special cases, ... Indexing axes
Corresponding to ... DB21, ... DBX12.7, DBX12.6 ff (Traverse keys plus and minus for geometry axes)
DB31, ... DBX4.4 (traversing key disable)
