Page #896 background imageLoading...
Page #896 background image
Z2: NC/PLC interface signals
18.10 Positioning axes (P2)
Extended Functions
896 Function Manual, 03/2013, 6FC5397-1BP40-3BA1
DB31, ...
DBX61.1
Axial alarm
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
Effects:
The axis/spindle is stopped by the NCK via a braking ramp.
OPI variables: aaSnglAxStat = 5 (alarm)
$AA_SNGLAX_STAT = 5 (axial alarm is present)
DB31 ... DBX61.1 = 1 (axial alarm)
DB31, ...
DBX63.0
Reset executed
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
The following state is present after the reset:
The machine data of the axis/spindle is reloaded
DB31 ... DBX63.0 == 1 (reset executed)
DB31 ... DBX63.2 == 0 (axis stop active)
System variable $AA_SNGLAX_STAT == 1
OPI variables: aaSnglAxStat == 1
Corresponding to ... DB31, … DBX28.1 (reset)
DB31, ...
DBX63.1
PLC-controlled axis
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
Confirmation of the NC to the PLC that the axis is now controlled by the PLC.
Corresponding to ... DB31 ... DBX28.7 (PLC controls the axis)
System variable: $AA_SNGLAX_STAT
DB31, …
DBX63.2
Axis stop active
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
Signal from the NC to the PLC that the axis will be stopped.
