Z2: NC/PLC interface signals
18.11 Oscillation (P5)
Extended Functions
Function Manual, 03/2013, 6FC5397-1BP40-3BA1
899
DB31, ...
DBX28.3
Set reversal point
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
Reversal point 2
Signal state 0 or edge
change 1 → 0
Reversal point 1
DB31, …
DBX28.4
Alter reversal point
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
The selected reversal point can be altered by manual traverse.
In conjunction with DB31, ...DBX28.0:
The position at which axis is braked after external oscillation reversal must be accepted as
new reversal point.
Signal state 0 or edge
change 1 → 0
The selected reversal point cannot be altered by manual traverse.
In conjunction with DB31, ...DBX28.0:
No change to reversal point
Corresponding to .... DBX28.3
DB31, ...
DBX28.5
Stop at next reversal point
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
The oscillation movement is interrupted at the next reversal point.
Signal state 0 or edge
change 1 → 0
The oscillation movement continues after the next reversal point.
Corresponding to .... DBX28.6, DBX28.7
DB31, ...
DBX28.6
Stop along braking ramp
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
The axis is decelerated along a ramp, the oscillation movement is interrupted.
Signal state 0 or edge
change 1 → 0
The oscillation movement continues without interruption.
Corresponding to .... DBX28.5, DBX28.7
