Description
Thedepthmeasurebytheselectedchannelis
shown.Inthiscontext,thephrasechannelisused
asacommontermtoidentifythecombinationof
transceiver,transducerandoperatingfrequency.
Tip
Bydefault,thedepthisshowninmeters.Youcan
changethemeasurementunitontheUnitspage.
TheUnitspageislocatedintheInstallationdialogbox.
SelectingSetupintheDepthinformationpaneopenstheBottomDetectionpageinthe
InformationPaneOptionsdialogbox.ThepurposeoftheBottomDetectionparameters
aretodenetheupperandlowerdepthlimitsmostlikelytobeusedduringtheES80
operation.
Tip
Ifyouhaveproblemswithbottomdetection,youmayconsiderdisablingit.Thiscanbe
usefulifyouonlywishtostudytargetsinthewatercolumn.UsethededicatedBottom
Detectionfunction.
Beforeyouopenaninformationpane,youmustrstclickinanechogramviewto
makeit"active".Bydoingthisyouselectthechannel.Inmostcases,thedatainthe
informationpaneisonlyvalidfortheselectedchannel.Inthiscontext,thephrase
channelisusedasacommontermtoidentifythecombinationoftransceiver,transducer
andoperatingfrequency.
Youcaneasilychangethephysicalsizeandshapeofeachinformationpane.
Clickinitslowerrightcorner,anddragtoanewsize.Toresettheinformation
panetoitsdefaultsize,selecttheResetsizebuttoninitstoprightcorner.
TheTransparencyfunctionallowsyoutoadjusthowmuchyouareabletosee"through"
theinformationpanesyouhaveopened.Youcanadjustthesettingfrom0%(no
transparency)to90%(almostfulltransparency)instepsof10%.
Details
Close
Selectthisbuttontoclosetheinformationpane.Thepanecloses
immediately.Ifyouwishtoreopenit,simplyclickthebuttononthetop
baronemoretime.
SimradES80ReferenceManual
