406273/C
247
Distributioninformationpane.TheSizeDistributionpageislocatedintheInformation
PaneOptionsdialogbox.TheInformationPaneOptionsdialogboxislocatedonthe
Activemenu.
Bydefault,youhavetwoechogramsforeachfrequencychannel.Thepresentationis
splithorizontallytoshowtheseechograms.Theinformationpaneprovidesinformation
aboutitssource,thatisfromwhichechogramthedatacomesfrom.Thefollowing
sourcescanbeshown:
•Source:LowerEchogram
•Source:UpperEchogram
•Source:Zoom
Beforeyouopenaninformationpane,youmustîš¿rstclickinanechogramviewto
makeit"active".Bydoingthisyouselectthechannel.Inmostcases,thedatainthe
informationpaneisonlyvalidfortheselectedchannel.Inthiscontext,thephrase
channelisusedasacommontermtoidentifythecombinationoftransceiver,transducer
andoperatingfrequency.
Youcaneasilychangethephysicalsizeandshapeofeachinformationpane.
Clickinitslowerrightcorner,anddragtoanewsize.Toresettheinformation
panetoitsdefaultsize,selecttheResetsizebuttoninitstoprightcorner.
TheTransparencyfunctionallowsyoutoadjusthowmuchyouareabletosee"through"
theinformationpanesyouhaveopened.Youcanadjustthesettingfrom0%(no
transparency)to90%(almostfulltransparency)instepsof10%.
Details
Close
Selectthisbuttontoclosetheinformationpane.Thepanecloses
immediately.Ifyouwishtoreopenit,simplyclickthebuttononthetop
baronemoretime.
Resetsize
Youmayhavemanuallychangedthephysicalsizeoftheinformation
pane.Toresettheinformationpanetoitsdefaultsize,selecttheReset
sizebuttoninitstoprightcorner.
Setup
SelectSetuptoopentheInformationPaneOptionsdialogbox.Thisdialog
boxallowsyoutochangethepresentationparametersrelatedtothe
informationpane.
Relatedtasks
Selectingîš¿shspeciesandchangingtheirsizetoimprovethesizedistribution
information,page139
Userinterface
