406273/C

March2019©KongsbergMaritimeAS

SimradES80

Widebandshndingechosounder

ReferenceManual

Release1.3.x

Thepurposeofthismanualistoprovidethedescriptionsand

proceduresrequiredtoallowforsafeandefcientuseoftheSimrad

ES80.Themanualalsooffersathoroughunderstandingofthevarious

ES80operationalsettingsandadjustments.

Caution

YoumustneverstartES80transmissions("pinging")whentheshipis

indrydock.Thetransducermaybedamagedifittransmitsinopenair.

TheinformationinthismanualisalsoavailableintheES80

context-sensitiveOn-linehelp.
