146 TimeProvider 5000 User’s Guide 098-00028-000 Revision F – May, 2012
Chapter 3
TimeProvider 5000 CLI Command Set
Level : User, Config, and Admin
set image
Use this command to provision the module firmware image from which to boot. The
backup image is the inactive (non-boot) image.
Command Syntax:
set image {imc|ioc1|ioc2|exp[0-9]}[1|2]
Example 1:
To set the IMC to boot image 1 
tp5000> set image imc 1
Example 2:
To set expansion shelf 4 (id=3) to boot image 2 
tp5000> set image exp3 2
Example 3:
To set IOC1 to boot image 2 
tp5000> set image ioc1 2
Remark: The module must be rebooted to implement the boot image.
Level : Admin only
Note: Each image has it's own set of configuration data. If Image 1 is
set as the boot image, the configuration data for Image 1 is applied
when the TP 5000 is rebooted. If Image 2 is set as the boot image,
the configuration data for Image 2 is applied when the TP 5000 is
rebooted.
A firmware upgrade is applied to the backup image, and the backup
image is set to be the next boot image. The TP 5000 copies the
currently running configuration data to the data used with the next
boot. Therefore, the configuration should be the same after rebooting,
except for changes due to differences in supported configuration
items between firmware revisions..
