Symmetricom TimeProvider 5000 User Manual

098-00028-000 Revision F – May, 2012 TimeProvider 5000 User’s Guide 181
Chapter 3
TimeProvider 5000 CLI Command Set
 frame type
 CRC (for CAS or CCS frametypes only)
 SSM (for frame type ESF, CCS with CRC, or CAS with CRC)
 SSM-bit (for frame type ESF, CCS with CRC, or CAS with CRC)
 output generation behavior in warm-up, free-run, fast-track, and holdover states
 test-mode (creates a T1-isolated pulse on the selected output port)
Priority Quality Level (PQL) values are listed in the following table.
If the output frame type supports SSM and SSM is enabled for the output port, then
the output signal will contain the system SSM value. The table below shows the
output SSM value based on the clock state of the TP5000
Note: If the 1PPS and 10M I/O module is installed (version
090-50312-01 or 090-50314-01), configuration updates for port
3 and port 4 will be accepted but not used.
Quality Level DS1 SSM E1 SSM Description
1 0x04 0x02 Stratum 1/PRS/PRC
2 0x08 0x00 STU, Stratum Unknown (presumed ST1)
3 0x0C 0x04 Stratum 2/Type II
4 0x0C 0x04 Type I
5 0x78 0x04 Transit Node/Type V
6 0x7C 0x08 Type III/Stratum 3E
7 0x10 0x0B Type IV/Stratum 3
8 0x22 0x0F G.813OPT3/SMC
9 0x30 0x0F DUS, Do not Use for Sync
15 --- --- Did not receive valid SSM
Clock State Output SSM
Warm-up PQL=9 - Do not use for Sync (DUS)
Free-run PQL of oscillator
Fast-lock PQL of oscillator
Normal PQL of reference
