180 TimeProvider 5000 User’s Guide 098-00028-000 Revision F – May, 2012
Chapter 3
TimeProvider 5000 CLI Command Set
show output-config
This command displays the System's output settings and whether the settings for a
port are used. The output settings will not be used if the port is configured as an
input, is a dedicated 10MHz or 1PPS output, or the port has been configured for test
mode. Ports 1 and 2 are programmable I/O ports. Ports 3 and 4 are dedicated
output ports.
Command Syntax:
show output-config
Example:
tp5000> show output-config
Response:
-------------------------------------------------------------------
|Port ID | State | Frame Type |CRC St |SSM St |SSM Bit|Config Used|
|--------|-------|------------|-------|-------|-------|-----------|
| port1 |enable |freq2048khz |disable|disable| 8 | T1pulse |
|........|.......|............|.......|.......|.......|...........|
| port2 |enable |freq2048khz |disable|disable| 8 | no |
|........|.......|............|.......|.......|.......|...........|
| port3 |enable |freq2048khz |disable|disable| 8 | no |
|........|.......|............|.......|.......|.......|...........|
| port4 |enable |freq2048khz |disable|disable| 8 | no |
|........|.......|............|.......|.......|.......|...........|
Note: See 'show io-status' for current port status and direction.
Related : Show Output-10M-config, Show Output-PPS-config
Level : User, Config, and Admin
set output
Use this command to provision the system's output ports. This command allows you
to provision:
 state
Note: For version 090-50311-01 of the I/O module, Ports 3 and
4 are dedicated E1 outputs ports. For versions 090-50312-01
and 090-50314-01 of the I/O module, Ports 3 and 4 are
dedicated 1PPS and 10M outputs ports.
