098-00028-000 Revision F – May, 2012 TimeProvider 5000 User’s Guide 205
Chapter 3
TimeProvider 5000 CLI Command Set
set ptp profile ioc1-[y] {default | hybrid | itu-g8265-1 |
telecom-2008}
To provision the management addressing mode as Multicast or Unicast:
set ptp mgmt-addr-mode ioc1-[y] {unicast | multicast}
To provision the state of the Two-Step Clock mode:
set ptp two-step {ioc1-1 | ioc1-2 | exp[0-9]} {enable |
disable}
– If the Two-Step Clock state is Disable, a One-Step Clock is used.
To provision the timescale for IOC1 or expansion shelf 1 -10 (id= exp0 - exp9) to
Automatic, Arbitrary or PTP:
set ptp timescale {ioc1 | exp[0-9]} {auto| arb | ptp}
– If the timescale is set to “auto”, the TP5000 will make the decision based
on the input. The TP5000 will set the timescale to “ptp” if the unit is locked
to gps. The TP5000 will set the timescale to “arb” if the unit is locked to
any other reference besides gps (i.e. E1 and T1).
To provision the Alternate Master mode:
set ptp alternative-master {ioc1-1 | ioc1-2 | exp[0-9]}
{enable | disable}
To provision the state for the specified PTP port on the IOC card or expansion
shelf:
set ptp state {ioc1-1 | ioc1-2 | exp[0-9]} {enable | disable}
To provision the IP Header Time to Live (TTL) field for PTP packets:
set ptp ttl {ioc1-1 | ioc1-2} <TTL-value>
To provision the PTP maximum number of clients:
Note: The ptp profile command replaces the ptp addr-mode
command.
Note: Management addressing mode controls whether PTP
management messages use Multicast or Unicast. This is independent
of the set ptp profile command. For example, management
addressing can be set for Multicast while PTP synchronization is
using Unicast. For multicast management, the client must be in the
TP5000's client list.
Note: If the Alternate Master mode is set to Enable, the alternate
master flag will be set in the PTP messages.
