Trimble CFX-750 User Manual

Digital Output 192
Advanced User Config 193
NMEA Output 194
Unlock / Upgrade 195
Unlock features using screens 195
Unlock features using USBdrive 196
Upgrade your display's firmware 196
Status 196
About the display 198
Restore defaults 198
Recalibrate touchscreen 198
13 Operations 201
Map guidance and features 202
Distance between guidance lines 202
Headlands 202
On-screen appearance 202
Guidance line / pattern mapping 203
Straight AB 204
Map an AB line 204
A+ line 205
Map an A+ line 205
Identical curve 205
Map an identical curve 206
Pivot 206
Map a pivot 206
Headland 207
Number of circuits 207
Internal pattern 208
Re-select the headland 208
Map a headland 208
Create straight sections on Headland swaths 209
FreeForm 209
Record a FreeForm curve 210
Use the FreeForm pattern to define a straight AB line 210
Switch to another line 210
Use FreeForm curves in spiral fields 210
Use FreeForm curves in fields with variable terrain 211
Use guidance on curved segments 211
Pause / Resume guidance 211
Resetting guidance 212
Guidance mapping buttons 213
Feature mapping buttons 214
Line Feature 214
Version 7.0, Revision A CFX-750 Display User Guide 13
Contents

Trimble CFX-750 Specifications

General

Resolution	800 x 600 pixels
GPS Compatibility	Yes
Power Supply	12 V DC
GNSS	GPS, GLONASS
Guidance	Yes
Mapping	Yes
Data Logging	Yes
ISOBUS	No
Display Type	Touchscreen
Connectivity	USB, CAN
Operating Temperature	-20°C to 55°C
Display Size	8.0 inches
