Control setup for a location 6 Field-IQ crop input control setup
Setting Explanation
On Latency
The length of time before a material is applied when the section is
turned on.
Off Latency
The length of time before a material stops applying after the
section is turned off.
3.
At the Overlap screen, set the amount of overlap you intend to have when applying material.
When you are finished with these settings, tap .
Setting Explanation
Start Overlap The amount of intentional overlap required when leaving
already covered area and going into a non-covered section of
the field.
End Overlap The amount of intentional overlap required when going into a
covered area.
Coverage Switch Overlap The amount of side-to-side coverage overlap before a section
shuts down.
Boundary Switch Overlap The amount of side to side boundary overlap before a section
shuts down.
4. Coverage Allowable Rate Error:Use this setting only if you are running very large fields. Then
tap .
5.
At the Section Control Module Location screen, complete the settings for each module. When
you are finished with these settings, tap .
Setting Explanation
Modules
Tap the serial number of the module you want to assign to the
location.
Number of Sections
Select the number of sections to assign to the selected module.
Version 7.0, Revision A CFX-750 Display User Guide 131
