6 Field-IQ crop input control setup Control setup for a location
Setting Explanation
Control Type
ll AirClutch: The section control module sends power to the
section valve to turn the clutch on to stop planting.
l Boom Valve: The section control module sends power to the
section valve to turn the boom valves off.
l Electric Clutch: The section control module sends power to
the electric clutch to stop panting.
l LiquiBlock: The section control module sends power to the
boom nozzles off.
Turn Off When Stopped
ll Yes:The section closes (turns off) when stopped.
l No:The section remains open (turned on) when stopped.
6.
At the Section Grouping screen, complete the settings to match how the sections are physically
configured on the implement. When you are finished with these settings, tap .
Setting Explanation
Restore Defaults
Return the settings to default.
Note – For the default, rows are divided evenly across all
sections. In most applications, this will be the correct setup.
Section button(s) Start with Section 1 and select the number of rows that are
connected.Continue with the sections in sequence until all rows
are assigned.
