Xerox WORKCENTRE 3210 Service Manual

WorkCentre 3210/3220 Multifunction Printer Service Manual 3-11
Error Messages and Codes
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Main Controller Board, PL1.0.2
■ Power Supply, PL1.0.4
■ Feed Actuator, PL4.0.72
■ Fuser, PL8.0.0
■ Exit Sensor, PL8.0.37
■ Map 5 - Main Controller Board
■ Map 7 - Power Supply
■ Power and Fuser
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the Feed Actuator installation.
Reseat the Feed Actuator.
Does the error still occur?
Replace the
Feed Actuator
(page 8-82).
Go to step 2.
Complete.
2 Does the error still occur? Go to step 3. Complete.
3 Check the Exit Sensor for damage.
Is the Exit Sensor damaged?
Replace the Exit
Sensor
(page 8-93).
Go to step 4.
4 Check the Power Supply installation.
Reseat Power Supply connections.
Does the error still occur?
Replace the
Power Supply
(page 8-104).
Go to step 5.
Complete.
5 Check the Main Controller Board for
correct installation. Reseat the Main
Controller Board.
Does the error still occur?
Replace the
Main Controller
Board
(page 8-100).
Complete.
