Xerox WORKCENTRE 3210 - Control Panel

WorkCentre 3210/3220 Multifunction Printer Service Manual 8-67
Service Parts Disassembly
Control Panel
PL6.3.1
1. Remove the ADF (page 8-31).
2. Pry the Control Panel bezel and remove the Control Panel bezel.
3. Use a flat tip screwdriver to pry the Control Panel to release the 4 clips.
s3210mfp-207
Clip
s3210mfp-208
