WorkCentre 3210/3220 Multifunction Printer Service Manual 3-23
Error Messages and Codes
Fuser Errors
Warning
Hazardous voltage is connected to the Fuser. Remove the Power Cord from
the printer before starting the procedure.
Fuser Heat Errors
There is a Fuser thermal error.
Warning
Allow the Fuser to cool before starting the procedure.
Applicable Error Messages
■ Open Heat Error
■ Low Heat Error
■ Over Heat Error
Initial Actions
■ Check the Fuser for damage or debris.
■ Cycle printer power.
■ If the problem persists, refer to the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map Reference
■ Fuser, PL8.0.0
■ Thermistor, PL8.0.5
■ Thermostat, PL8.0.7
■ Halogen Lamp, PL8.0.30
■ Map 5 - Main Controller Board
■ Map 7 - Power Supply
■ Map 8 - Left Side Harness
■ Power and Fuser
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Reseat the Fuser connections.
Does the error still occur?
Go to step 2. Complete.
2 Run the Fuser Temp test from EDC.
Does the Thermostat operate
correctly?
Go to step 3. Replace the
Thermostat
(
page 8-16).

Xerox WORKCENTRE 3210 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed	Up to 24 ppm
Duplex Printing	Manual
Monthly Duty Cycle	Up to 30, 000 pages
Processor Speed	360 MHz
Memory	128 MB
Standard Paper Capacity	250 sheets
Scanner Type	Flatbed, ADF
Fax Transmission Speed	33.6 Kbps
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Folio, Legal, Letter
Scan Resolution	Up to 4800 x 4800 dpi
Maximum Paper Size	8.5 x 14 in (Legal)
Operating System Compatibility	Windows, Mac OS
Print Resolution	600 x 600 dpi
