Page #345 background image
WorkCentre 3210/3220 Multifunction Printer Service Manual 9-3
Parts List
Using the Parts List
ID No.: The callout number from the exploded part diagram.
Name/Description: The name of the part to be ordered and the number
of parts supplied per order.
Part Number: The material part number used to order that specific part.
Parts identified throughout this manual are referenced PL#.#.#; For
example, PL3.1.10 means the part is item 10 of Parts List 3.1.
A black triangle preceding a number followed by a parenthetical statement
in an illustrated parts list means the item is a parent assembly, made up of
the individual parts called out in parentheses.
The notation “with X~Y” following a part name indicates an assembly that
is made up of components X through Y. For example, “1 (with 2~4)”
means part 1 consists of part 2, part 3, and part 4.
An asterisk (*) following a part name indicates the page contains a note
about this part.
The notation (NS) next to a part indicates that particular part is not
spared, but contained in a kit or major assembly.
The notation “J1<>J2 and P2” is attached to a wire harness. It indicates
that connector Jack 1 is attached to one end of the wire harness and
connector J2 is attached to the other end that is plugged into P2.
Note
Only parts showing part numbers are available for ordering by support.
Parts not
showing part numbers are available on the parent assembly.
Abbreviations
Abbreviation Meaning
C C-ring
E E-ring
KL K-clip
S Screw
