8-62 WorkCentre 3210/3220 Multifunction Printer Service Manual
Service Parts Disassembly
Right Cover
PL2.0.4
1. Remove the Front Cover (page 8-58).
2. Remove the Duplex Unit (page 8-69).
3. Remove the Rear Cover (page 8-61).
4. Remove 1 screw (12 mm, silver) that secures the Right Cover.
To Next Page
