WorkCentre 3210/3220 Multifunction Printer Service Manual 8-93
Service Parts Disassembly
Exit Sensor
PL8.0.37
Allow the Fuser to cool before performing this procedure.
1. Remove the Print Cartridge (page 8-8).
2. Remove the Front Cover (page 8-58).
3. Remove the Fuser (page 8-13).
4. Release the tab to remove the right lamp cap.
To Next Page
