WorkCentre 3210/3220 Multifunction Printer Service Manual 4-23
General Troubleshooting
Power Supply Troubleshooting
Warning
Hazardous voltage is connected to the wall outlet.
AC Power Troubleshooting
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack References
■ Power Supply, PL1.0.4 ■ Map 7 - Power Supply
■ Power and Fuser
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the voltage at the AC wall outlet.
Is there approximately 110 VAC (or
220
VAC if the printer is a 220 V
configuration) at the AC wall outlet?
Go to step 2. Notify the
customer of
improper AC
output from
the outlet.
2 Check the power cord for defects or loose
connection.
Is the Power Cord loose or defective?
Replace or
reconnect the
Power Cord.
Replace the
Power Supply
(
page 8-104).

Xerox WORKCENTRE 3210 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed	Up to 24 ppm
Duplex Printing	Manual
Monthly Duty Cycle	Up to 30, 000 pages
Processor Speed	360 MHz
Memory	128 MB
Standard Paper Capacity	250 sheets
Scanner Type	Flatbed, ADF
Fax Transmission Speed	33.6 Kbps
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Folio, Legal, Letter
Scan Resolution	Up to 4800 x 4800 dpi
Maximum Paper Size	8.5 x 14 in (Legal)
Operating System Compatibility	Windows, Mac OS
Print Resolution	600 x 600 dpi
