WorkCentre 3210/3220 Multifunction Printer Service Manual 5-39
Print-Quality Troubleshooting
Print-Quality Specifications
The Print-Quality specifications are as follows.
Skew
Vertical Skew
■ ±2.0 mm (Tray 1) / 241.3 mm
■ ±2.5 mm (Duplex, SCF) / 241.3 mm
■ ±3.5 mm (ADF) / 241.3 mm
Horizontal Skew
■ ±1.5 mm (Tray 1: ± 2.0 mm) / 177.8 mm
■ ±2.0 mm (Duplex, SCF) / 177.8 mm
■ ±2.5 mm (ADF) / 177.8 mm
Curl
For 20lb paper
■ 20 mm (0.79") Max, Environment: at NN condition with 5% page
coverage,
■ 30 mm (1.18") Max, Environment: at LL/HH condition with 5% page
coverage
For 24lb paper
■ 30 mm (1.18") Max, Environment: at all condition with 5% page coverage,
Measure the highest corner of 10 sheets of simplex output 5 minutes after
output on flat surface. Load the paper as indicated on the wrapper. If there is
no designation for proper paper up-side, test using both sides.
Registration
Left print position (scanning direction): ± 2.5mm (±3.0mm, Duplex)
Top print position (feeding direction): ± 3.0mm (±3.0mm, Duplex)
Noise
System noise specifications from different feed locations.
■ Printing (Tray 1): 50dB
■ Printing (Tray 2): 55dB
■ ADF: 53dB
■ Platen: 52dB

Xerox WORKCENTRE 3210 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed	Up to 24 ppm
Duplex Printing	Manual
Monthly Duty Cycle	Up to 30, 000 pages
Processor Speed	360 MHz
Memory	128 MB
Standard Paper Capacity	250 sheets
Scanner Type	Flatbed, ADF
Fax Transmission Speed	33.6 Kbps
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Folio, Legal, Letter
Scan Resolution	Up to 4800 x 4800 dpi
Maximum Paper Size	8.5 x 14 in (Legal)
Operating System Compatibility	Windows, Mac OS
Print Resolution	600 x 600 dpi
