Xerox WORKCENTRE 3210 Service Manual

10-16 WorkCentre 3210/3220 Multifunction Printer Service Manual
Wiring
Main Controller Board
Main Controller
Board
CN21
3
4
nDEV_DET
+5VDC
Laser Unit
Interlock Switch
CN13
1
2
3
CN37
3
2
1
GND
nSENS_P_EMPTY
nSENS_P_REGI
nSENS_P_FEED
+3.3VDC
+24VDC
+5VDC
+3.3VDC
11
+24VDC
12
REGI_CLUTCH
FAN_LSU
Registration
Clutch
13
+24VDC
GND
14
PICKUP_CLUTCH
Pick-Up
Solenoid
s3210mfp-106
Paper Empty
Sensor
CN12
1
2
3
CN41
3
2
1
GND
nSENS_OUTBIN_FULL
+3.3VDC
Outbin Sensor
4
5
6
CN38
3
2
1
GND
+3.3VDC
Duplex
Registration
Sensor
7
8
9
CN39
3
2
1
GND
+3.3VDC
Feed Sensor
CN31
Main Motor
BLDC_MOTOR_READY
M
nBLDC_MOTOR_EN
GND
BLDC_MOTOR_BREAK
GND
GND
10
9
8
7
6
5
4
3
2
1
nBLDC_MOTOR_DIR
BLDC_CLK
+24VDC
+24VDC
1
2
3
4
5
6
7
8
9
10
CN9
CN33
CN32
CN11 CN48
CN2
1
2
1
2
1
2
FAN_MAIN
1
2
3
GND
GND
DC Fan
(Laser Unit Fan)
Main Fan
FAN_LVPS
1
2
1
2
+24VDC
Power Supply Fan

Xerox WORKCENTRE 3210 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed	Up to 24 ppm
Duplex Printing	Manual
Monthly Duty Cycle	Up to 30, 000 pages
Processor Speed	360 MHz
Memory	128 MB
Standard Paper Capacity	250 sheets
Scanner Type	Flatbed, ADF
Fax Transmission Speed	33.6 Kbps
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Folio, Legal, Letter
Scan Resolution	Up to 4800 x 4800 dpi
Maximum Paper Size	8.5 x 14 in (Legal)
Operating System Compatibility	Windows, Mac OS
Print Resolution	600 x 600 dpi
