WorkCentre 3210/3220 Multifunction Printer Service Manual 5-37
Print-Quality Troubleshooting
TP 7 Skew
TP 7 is used to check image skew on the media. The print provides
instructions for calculating skew performance.
TP 8 Text
TP 8 is used to check text uniformity.
s3210mfp-203
AB C
DE F
GH I
s3210mfp-204
