Xerox WORKCENTRE 3210 Service Manual

WorkCentre 3210/3220 Multifunction Printer Service Manual 10-19
Wiring
Laser Unit and I/O
Main Controller
Board
+3.3VDC
+24VDC
+5VDC
s3210mfp-109
CN13
Laser Unit
GND
HSYNC_1
nSH_LSU_1
GND
GND
VDO_1_N
VDO_2_P
nLDON_LSU
LD_POWER1
GND
NC
RD-
+3.3VAC_CTR_TAP
+3.3VAC_CTR_TAP
LED1_POWER
LED2_POWER
LED1
LED2
RD+
TD-
TD+
5V_LSU
6
7
8
9
10
11
12
13
14
15
CN7
nLSU_MOT_EN
nREADY_LSU
CLK_LSU_MOT
+24VAC
GND
1
2
3
4
5
Ethernet
1
2
3
4
5
6
7
8
9
10
11
12
CN6
VBUS
DM1
DP1
GND
USB
1
2
3
4
CN15
+5VDC
DM3
DP3
GND
USB (Front)
1
2
3
4

Xerox WORKCENTRE 3210 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed	Up to 24 ppm
Duplex Printing	Manual
Monthly Duty Cycle	Up to 30, 000 pages
Processor Speed	360 MHz
Memory	128 MB
Standard Paper Capacity	250 sheets
Scanner Type	Flatbed, ADF
Fax Transmission Speed	33.6 Kbps
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Folio, Legal, Letter
Scan Resolution	Up to 4800 x 4800 dpi
Maximum Paper Size	8.5 x 14 in (Legal)
Operating System Compatibility	Windows, Mac OS
Print Resolution	600 x 600 dpi
