WorkCentre 3210/3220 Multifunction Printer Service Manual 4-3
General Troubleshooting
Tech Mode
Tech mode provides an interface to set or adjust various communication
parameters, perform system-level tests, print test prints, or generate reports
of system activity. While in Tech mode, the printer continues to perform all
normal operations.
What follows are descriptions of each Tech mode option available under the
three main functional categories; Data Setup, Machine Test, and Report.
Entering Tech Mode
To enter Tech mode, pressthese keys in sequence
The LCD displays ‘Tech Mode, Tech Menu, indicating the machine has
entered service (tech) mode.
Fuser Ctrl ■ Temp Control
■ Fuser Temp
Select On to switch the Fuser on and view the
temperature. Off turns the Fuser Off and displays
0. Fuser Temp displays the current Fuser
temperature.
LSU Control ■ LD Power
■ LSU Motor
■ LSU Ready
■ Hsync
Press OK after On appears on the display to run
the test for 10 seconds. For LSU Ready and the
Hsync, the test reports “1” if successful.
DEV Control ■ THV +
■ THV -
■ Dev Bias
■ MHV Bias
Press OK after On appears on the display to turn
the selected control signal On.
EDC Tests (continued)
Component Test Description
Menu Menu
s3210mfp-257

Xerox WORKCENTRE 3210 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed	Up to 24 ppm
Duplex Printing	Manual
Monthly Duty Cycle	Up to 30, 000 pages
Processor Speed	360 MHz
Memory	128 MB
Standard Paper Capacity	250 sheets
Scanner Type	Flatbed, ADF
Fax Transmission Speed	33.6 Kbps
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Folio, Legal, Letter
Scan Resolution	Up to 4800 x 4800 dpi
Maximum Paper Size	8.5 x 14 in (Legal)
Operating System Compatibility	Windows, Mac OS
Print Resolution	600 x 600 dpi
