10-2 WorkCentre 3210/3220 Multifunction Printer Service Manual
Wiring
Component Locator Diagrams
This chapter contains the plug/jack designators, component locator diagrams,
and wiring diagrams for the print engine, scanner, and ADF.
Component Locator
Maps 1 through 3 indicate the location of key components within the printer.
1. Map 1 - Circuit Board Locator
2. Map 2 - Drive Locator
3. Map 3 - Sensor Locator
Component Locator
Component Map Coordinates
ADF Control Board 1 D-14
Control Panel 1 B-16
Main Controller Board 1 I-17
Power Supply (SMPS) 1 H-19
HVPS 1 G-19
ADF Motor Assembly 2 E-33
Main Motor Assembly 2 C-38
Registration Clutch 2 B-39
Pick Up Solenoid 2 B-39
Scanner Motor 2 I-36
ADF Registration Sensor 3 D-73
ADF Exit Sensor 3 D-73
ADF No Paper Sensor 3 D-74
Interlock Switch 3 F-74
Output Tray Full Sensor 3 H-74
Exit Sensor 3 I-77
Rear Cover Interlock Switch 3 H-78
Front Cover Interlock Switch 3 G-79
Duplex Registration Sensor 3 F-79
Tray Feed Sensor 3 F-79
Tray No Paper Sensor 3 E-79
Laser Unit Fan 4 D-57
Main Fan 4 I-58
Power Supply Fan 4 H-60
