WorkCentre 3210/3220 Multifunction Printer Service Manual 8-101
Service Parts Disassembly
High Voltage Power Supply
PL1.0.3
1. Remove the Right Cover (page 8-62).
2. Remove 6 screws (12 mm, silver) that secure the HVPS.
s3210mfp-061
