8-102 WorkCentre 3210/3220 Multifunction Printer Service Manual
Service Parts Disassembly
3. Disconnect the wiring harness connector CN1.
4. Remove the HVPS.
Replacement Note
Secure the 6 screws in order (1-6). Be careful not to drop the 4
Contact Springs.
s3210mfp-062
CN1
s3210mfp-063
