WorkCentre 3210/3220 Multifunction Printer Service Manual 4-15
General Troubleshooting
Fuser Gear Damaged from Overheating
There is a repetitive jam at the Fuser or the Fuser rollers are not turning.
Warning
Allow the Fuser to cool before beginning the procedure.
Initial Actions
■ Ensure that the Fuser is secured to the printer.
■ Cycle printer power.
■ If the problem persists, refer to the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map Reference
■ Main Controller Board, PL1.0.2
■ Power Supply, PL1.0.4
■ Fuser, PL8.0.0
■ Halogen Lamp, PL8.0.30
■ Map 1 - Circuit Board Locator
■ Map 5 - Main Controller Board
■ Power and Fuser
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the Halogen Lamp for damage
or overheating.
Is the Halogen Lamp damaged?
Replace the
Halogen Lamp
(
page 8-27).
Go to step 2.
2 Replace the Fuser (page 8-13).
Does the error still occur?
Replace the
Power Supply
(
page 8-104).
Go to step 3.
3 Reseat connections on the Main
Controller Board.
Does the error still occur?
Replace the
Main Controller
Board
(
page 8-100).
Complete.

Xerox WORKCENTRE 3210 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed	Up to 24 ppm
Duplex Printing	Manual
Monthly Duty Cycle	Up to 30, 000 pages
Processor Speed	360 MHz
Memory	128 MB
Standard Paper Capacity	250 sheets
Scanner Type	Flatbed, ADF
Fax Transmission Speed	33.6 Kbps
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Folio, Legal, Letter
Scan Resolution	Up to 4800 x 4800 dpi
Maximum Paper Size	8.5 x 14 in (Legal)
Operating System Compatibility	Windows, Mac OS
Print Resolution	600 x 600 dpi
