WorkCentre 3210/3220 Multifunction Printer Service Manual 8-81
Service Parts Disassembly
Exit Roller
PL4.0.59
Allow the Fuser to cool before performing this procedure.
1. Remove the Fuser (page 8-13).
2. Remove the Middle Cover (page 8-65).
3. Release the clip on the Exit Roller from the upper exit frame.
4. Remove the Exit Roller.
