8-24 WorkCentre 3210/3220 Multifunction Printer Service Manual
Service Parts Disassembly
Small Pressure Roller
PL8.0.23
Allow the Fuser to cool before performing this procedure.
1. Remove the Fuser (page 8-13).
Do not apply too much pressure while releasing the tab to prevent damaging
the lamp cap.
2. Release the tab and remove the right lamp cap.
To Next Page
