WorkCentre 3210/3220 Multifunction Printer Service Manual 8-23
Service Parts Disassembly
5. Remove the Small Pressure Roller (page 8-24).
6. On the wide open side of the fuser frame, slide the Large Pressure Roller
out from the fuser frame. On the small open side of the fuser frame, slide
the Large Pressure Roller out from the bushing.
s3210mfp-036
