WorkCentre 3210/3220 Multifunction Printer Service Manual 1-19
General Information
Physical Dimensions and Clearances
Printer Dimensions
Minimum Clearances
Print Engine WorkCentre 3210 WorkCentre 3220
Height 421.6 mm (16.6 in.) 421.6 mm (16.6 in.)
Width 444.5 mm (17.5 in.) 444.5 mm (17.5 in.)
Depth 393.7 mm (15.5 in.) 393.7 mm (15.5 in.)
Weight (base printer with
standard fill print cartridge)
17.8 kg (39.0 lb.) 17.8 kg (39.0 lb.)
Optional Tray Assembly
Height 91.4 mm (3.6 in.) 91.4 mm (3.6 in.)
Width 363.0 mm (14.3 in.) 363.0 mm (14.3 in.)
Depth 401.3 mm (15.8 in.) 401.3 mm (15.8 in.)
Weight 2.6 kg (5.7 lb.) 2.6 kg (5.7 lb.)
71.2 cm
(28 in.)
10 cm
(3.9 in.)
10 cm
(3.9 in.)
48.3 cm
(18.8 in.)
18 cm
(7.1 in.)
s3210mfp-009
