8-40 WorkCentre 3210/3220 Multifunction Printer Service Manual
Service Parts Disassembly
Upper ADF
PL6.1.7
1. Remove the ADF (page 8-31).
2. Turn the ADF over with the bottom side facing upward.
3. Remove 4 screws (12 mm, silver) that secure the ADF stacker and lower
ADF.
s3210mfp-155
