Xerox WORKCENTRE 3210 Service Manual

8-2 WorkCentre 3210/3220 Multifunction Printer Service Manual
Service Parts Disassembly
Overview
This section contains the removal procedures for field-replaceable parts of the
printer listed in the Parts List. In most cases, the replacement procedure is
simply the reverse of the removal procedure. In some instances, additional
steps are necessary and are provided for replacement of the parts. For
specific assemblies and parts, refer to the “
Parts List” in Section 9.
Note
Always use the correct type and size screw (page 8-5). Using the wrong
screw can damage tapped holes. Do not use excessive force to remove or
install either a screw or a printer part.
Standard Orientation of the Printer
When needed, the orientation of the printer is called out in the procedure as
an aid for locating the printer parts. The following illustration identifies the
Front, Rear, Left, and Right sides of the printer.
Front
Right
Left
Back
s3210mfp-090

Xerox WORKCENTRE 3210 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed	Up to 24 ppm
Duplex Printing	Manual
Monthly Duty Cycle	Up to 30, 000 pages
Processor Speed	360 MHz
Memory	128 MB
Standard Paper Capacity	250 sheets
Scanner Type	Flatbed, ADF
Fax Transmission Speed	33.6 Kbps
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Folio, Legal, Letter
Scan Resolution	Up to 4800 x 4800 dpi
Maximum Paper Size	8.5 x 14 in (Legal)
Operating System Compatibility	Windows, Mac OS
Print Resolution	600 x 600 dpi
